Functions:
Monitors RTD temperatures
Monitors 4-20 mA analog signals
RS-485 output
Features:
Eight inputs
Individually selectable input type (PT100, Ni100, Ni120, CU10 RTD, or 4-20 mA)
Up to 63 modules per network
Solid-state multiplexing
Open and short RTD detection
Compact size
Remote mounting - up to 1.2 km from network master
Modbus RTU communications
CSA Class 1 Zone 2 hazardous-location certified
Free SE-Comm-RTD PC-interface software
Conformally coated circuit boards
Five year warranty
Features:
Eight inputs
Individually selectable input type (PT100, Ni100, Ni120, CU10 RTD, or 4-20 mA)
Up to 63 modules per network
Solid-state multiplexing
Open and short RTD detection
Compact size
Remote mounting - up to 1.2 km from network master
Modbus RTU communications
CSA Class 1 Zone 2 hazardous-location certified
Free SE-Comm-RTD PC-interface software
Conformally coated circuit boards
Five year warranty
Manuals and Data Sheet:
SIO-RTD Data Sheet
SIO-RTD Manual
Manual SIO-RTD (Español)
Typical Applications:
Temperature measurement and 4-20-mA-output device monitoring in industrial environments
Minimum System Requirements:
Used as a slave on a Modbus communications network. It requires a Modbus master and 24-Vdc power supply. |
|
