Function:
Provides current to test trip pickup level, and coordination of ground-fault protection
Injects current through the window of ground-fault CT's to verify the operation of ground-fault monitors
Simplifies scheduled testing procedures
Features:
Tests the entire ground-fault circuit including CT's, wiring, ground-fault relay, and interrupting device
Two output-current levels (0.65 and 2.75 A)
One SE-100T can test several ground-fault devices
Multiple wraps through the ground-fault CT can provide additional current levels
Remote test input
Five year warranty
Manuals and Data Sheets:
SE-100T Data Sheet
SE-100T Manual
Hoja de datos SE-100T (Español)
Manual SE-100T (Español)
Typical Applications:
Used on MCC's, substations, central distribution panels (CDP's), and switchboards to verify relay operation
|
|
